Product Specification
| Sirles | Flip Switches |
| Model | HX MSS-23D18G2 |
| 1. Rating | 50mA 12VDC |
| 2. Constrution Dimension | Apply to the appended drawing |
| 3. Appearance | Have no remarkable damage, crack and rust etc. |
| 4. Contactloop | Monople loop |
Product Description
The MSS-23D18G2 125 Toggle Switch is a compact, high-reliability electrical switch designed for various control applications. Featuring a durable metal actuator and robust plastic housing, this toggle switch offers stable performance and smooth toggling action. Its DPDT (Double Pole Double Throw) configuration allows for versatile circuit control, making it ideal for both simple and complex operations.
- Item Name: Toggle Switch MSS-23D18G2 125
- Operating Temperature: -25 to 70℃
- Relative Humidity: ≤80%RH
- Rating: 50mA 12V DC
- Contact Resistance: ≤100mΩ
- Resistance Insulation: ≥100mΩ
- Operating Force: 250gf±50gf
- Dielectric Strength: 250V 50Hz 1min
- Contact Journey: 2±0.2mm
- Lifetime: 10, 000 cycles
Application Field
-
Industrial control panels
-
Automotive systems
-
Household appliances
-
Communication equipment
-
Power tools and machinery
-
Marine and RV applications
Why Choose Us
Extensive Industry Experience
Founded in 2014, Hanxia has over 10 years of expertise in electronic component manufacturing. We proudly serve 7,500+ customers across global markets including the United States, Germany, South Korea, Taiwan, and Hong Kong.
Advanced Automated Production
-
38 fully automated production lines ensure high-volume, consistent output.
-
Daily production capacity exceeds 2 million units, supporting fast and efficient order fulfillment.
-
Technical collaboration with Korean partners brings cutting-edge, fully automated assembly processes that reduce human error.
-
Fast, worry-free delivery, backed by a 90-day no-questions-asked return policy.
Uncompromising Quality Control
-
Every stage of production is carefully monitored—from raw material inspection to in-line sampling and final product testing.
-
We provide 100% factory inspection, guaranteeing that each product meets or exceeds customer expectations for quality, performance, and durability.
 |
 |
 |
 |
 |
 |
