Basic Information
| Item Name | Tact Switch |
| Model No. | TS36TP |
| Rating | 300mA.4V DC |
| Insulation Resistance | 100mΩ max 100V DC |
| Dielectric Strength | 250V AC for 1 min |
| Contact Resistance | 70mΩ max. |
| Operating Temp. Range | -10℃~+7℃ |
| Lifetime | 10,000 cycles min |
| Operating Force | 120±50gf 2C-2P: 200±50gf |
| Travel | 1.5±0.2mm 2.0±0.2mm |
Product Description
The SMD Tact Switch 3×6 2Pin by Hanxia features a small 3x6mm form factor with two pins, making it ideal for space-constrained medical devices such as glucose meters. The switch offers smooth tactile feedback, providing users with clear indication of activation. Its durability and sensitivity ensure a reliable performance in medical testing, helping people manage their diabetes more effectively.
- Rating: DC12V 50mA
- Travel: 0.25±0.1mm
- Operation Force： 260±30gf
- Being measure at across spring piece and across Key stoke for ergo meter.
- Contact Resistance：50mΩMax.
- Addition 1.5-2 time force on the top of the key strok and press the switch,DC50V100mA
- Life time：50000 Cycles Min.
- Operation at a rate of 30-50 cycles a minute.
Factory strengths: with 13 years of industry experience, the company has passed ISO9001 certification, a number of patent certificates, more than 5300 cooperative customers, many customers of listed companies, 106 employees, 12 hardware punches, 18 injection molding machines, 26 full-automatic assembly machines, 32 full-automatic testing machines, 21 semi-automatic testing machines, 12 life testing machines and 25 other testing equipment.
Application Field
-
Glucose Meters for Diabetes Testing: Primarily designed for glucose meters, the switch ensures easy and reliable operation for individuals managing diabetes.
-
Medical Devices: Suitable for other small medical devices requiring tactile feedback, such as blood pressure monitors, pulse oximeters, or digital thermometers.
-
Portable Health Monitoring Equipment: Ideal for portable health monitoring tools where space and reliable performance are essential.
Why Choose Us
At Hanxia, we are committed to delivering high-quality electronic components backed by reliable service and technical excellence. Here’s what sets us apart:
Extensive Industry Experience
Founded in 2014, Hanxia brings over a decade of expertise in electronic component manufacturing. We proudly serve 7,500+ customers across global markets, including the U.S., Germany, South Korea, Taiwan, and Hong Kong.
Advanced, Efficient Production
- 38 Fully Automated Production Lines: Capable of producing over 2 million units daily to ensure timely order fulfillment.
- Cutting-Edge Technology: In collaboration with Korean partners, we utilize fully automated assembly systems that reduce human error and improve precision.
- Fast, Hassle-Free Delivery: We offer risk-free shipping and a 90-day no-questions-asked return policy for complete peace of mind.
Strict Quality Control
Quality is built into every stage of our process:
- Material Inspection
- In-line Sampling
- Final Product Testing
 |
 |
 |
 |
 |
 |
