Product Specification
| Sirles | Tact Switches |
| Model | HX TS3735PA 250gf 030 |
| 1. Rating | 50mA 12VDC |
| 2. Constrution Dimension | Apply to the appended drawing |
| 3. Appearance | Have no remarkable damage, crack and rust etc. |
| 4. Contactloop | Monople loop |
Product Description
The Hanxia DIP 6×6 Waterproof Tact Switch is engineered to deliver reliable and long-lasting performance in moisture-prone environments, making it an excellent choice for washing machines and household appliances. With a water-resistant design and durable DIP mounting structure, it ensures smooth and safe operation in harsh usage conditions.
- Item Name: Tact Switch TS3735PA 250GF 030 Double Bomb 100,000
- Operating Temperature: -25 to 70℃
- Relative Humidity: ≤80%RH
- Rating: 50mA 12V DC
- Contact Resistance: ≤100mΩ
- Resistance Insulation: ≥100mΩ
- Operating Force: 250gf±50gf
- Dielectric Strength: 250V 50Hz 1min
- Contact Journey: 0.2±0.1mm
- Lifetime: 30, 000 cycles
Application Field
-
Washing machines
-
Dishwashers
-
Kitchen appliances
-
Bathroom electronics
-
Smart home devices in wet environments
